Round LED Displays for Slot Machines | Gaming & Advertising Screens
Customizable LED colors and patterns
Energy-efficient design for longevity
Easy installation and operation
Durable construction for high traffic
Interactive display options for engagement
Immersive LED Visual Solutions
Radiant delivers cutting-edge LED visual solutions engineered for immersive entertainment environments. Featuring circular gaming displays, ultra-clear transparent LED screens, and double-sided configurations. Engineered for casinos, luxury retail, and event venues with full customization of dimensions, curvature radii, and pixel pitch for seamless architectural integration.
Technical Advantages
- 6POD LED Signage SystemDynamic double-sided 180° viewing
- 8000nit Peak BrightnessWith intelligent auto-dimming
- Microsecond Response3840Hz refresh rate
Core Features
IP65
Weatherproof Construction
±60°
Curvature Flexibility
-30°C
Low-Temp Operation
15min
Quick Installation
System Specifications
Aircraft-grade aluminum alloy chassis with modular quick-install components
Oval/endcap solutions create continuous curved surfaces with R≥500mm radius
24/7 operation capability in -30°C to 55°C environments
5000-8000nit HDR performance with 16-bit color processing
Details Specification
| Item | RDT-GS003 | Pixel Pitch | 1.86mm,2.0mm,2.5mm,3.0mm | ||
| Module size | 240mm x 160mm | 320mm x 160mm | Cabinet size | Customized based on module size | |
| Cabinet Weight | 45 kg/m² | Physical Density | 289050dots/m²,250000 dots/m², 160000 dots/m²,111111dots/m², | ||
| Brightness | 800-1200nits | Refresh Rate | 1920-3840 Hz | ||
| Driving Mode | Constant Current | Gray Level | 16 bit | ||
| Working Voltage | 100-240V AC, 50&60Hz | Protection Level | IP43 | ||
| Maximum Power Consumption | 460W /m² | Average Power Consumption | 130W /m² | ||
| View Angle | 160ºH/140ºV | Viewing Distance | >1.8m,2m,2.5m,3m | ||
| Working Temperature | -10℃~ +50 ℃ | Working Humidity | 10 – 95 % RH | ||
| LED Life(Normal Tep) | 100,000 Hours | Software System | Novastar | ||
| Application | Indoor | Installation Type | Fixed installation | ||
| Maintenance Method | Front (Magnetic module) | Warranty | >2 years | ||
