P2.5 Flexible Curved LED Wall | Retail & Exhibition Digital Signage
Delivers sharp, clear images
Visible in any lighting condition, built to last
Low power consumption, eco-friendly
Modular for easy customization and installation
P2.5 curved LED display
Engineered to deliver exceptional visual performance with a
160° horizontal / 140° vertical viewing angle and
1000-1200 nits brightness (adjustable for ambient lighting)
ensuring vivid imagery in both indoor and outdoor environments.
Key Applications
- ✔️ Shopping mall atriumsTrade show exhibits
- ✔️ Museum installationsCorporate lobbies
- ✔️ Broadcast studiosInteractive digital experiences
Technical Highlights
Front Magnetic Maintenance
Tool-free servicing system
3840Hz
Refresh Rate
IP43
Durability
100,000-hour
Lifespan
Engineering Specifications
Pixel Pitch: 2.5mm (Optimal viewing >2.5m)
Energy Efficiency: 130W/m² average consumption
Modular Design: 240x160mm / 320x160mm panels
Control System: Novastar software integration
Details Specification
| Item | RDT-TS2.5 | RDT-TL2.5 | Pixel Pitch | 2.5mm | |
| Module size | 240mm x 160mm | 320mm x 160mm | Module Resolution | 96 x 64 pixels | 128 x 64 pixels |
| Module Weight | 0.32 kg | 0.4 kg | Physical Density | 160000 dots/m² | |
| Brightness | 1000-1200nits | Refresh Rate | 1920-3840 Hz | ||
| Driving Mode | Constant Current 1/32 | Gray Level | 16 bit | ||
| Working Voltage | 100-240V AC, 50&60Hz | Protection Level | IP43 | ||
| Maximum Power Consumption | 460W /m² | Average Power Consumption | 130W /m² | ||
| View Angle | 160ºH/140ºV | Viewing Distance | >2.5m | ||
| Working Temperature | -10℃~ +50 ℃ | Working Humidity | 10 – 95 % RH | ||
| LED Life(Normal Tep) | 100,000 Hours | Viewing Angle | 140°/140° | ||
| Application | Indoor | Installation Type | Fixed installation | ||
| Maintenance Method | Front (Magnetic module) | Software System | Novastar | ||
